| Part Number: | P53626-0AE |
|---|---|
| Manufacturer: | HPE |
| Servers Spare Parts: | Server Memory Kit |
| Model: | ML110 (G11) / ML350 (G11) / DL320 (G11) / DL360 (G11) |
| Description: | Buy HPE P53626-0AE 32GB DDR5-5600 Server Memory Kit. Genuine part with fast worldwide shipping from Euroland IT Store UK. |
| Availability: | In Stock |
Some HPE 32GB DDR5-5600 modules leave the factory with P53626-0AE on the label rather than the more common P53626-0A1. Resellers list both against the same product: HPE’s 32GB dual rank x8 registered Smart Memory kit, option number P64706-B21. If your failed DIMM shows the -0AE code, this is the matching replacement.
It is a 288-pin DDR5 RDIMM rated at 5600 MT/s with CL46 timings, EC8 error correction and 1.1V operation, designed for HPE Gen11 servers that run 5th Generation Intel Xeon Scalable processors.
We list it in New and Refurbished condition, subject to stock. Choose an option on the product page to see the condition and warranty that go with it.
For the buyer, nothing that affects fit or function. Both codes are assembly references that sit on the module label, and both are sold against option kit P64706-B21 as 32GB 2Rx8 PC5-5600B-R memory. HPE has used the same -0A1 and -0AE pattern across the wider 5600 MT/s range, for example on its 16GB and 64GB kits. HPE does not publish why a second suffix exists, so we treat the two labels as interchangeable for ordering purposes but always recommend matching the speed, rank and organisation printed on the DIMM.
The related numbers are spare part P65254-001, the P53626-0A1 label version, and PartSurfer spare P68074-001.
A Gen11 Intel server can be fitted with either 4th or 5th Gen Xeon Scalable processors, and the memory has to follow. HPE QuickSpecs say 5th Gen Emerald Rapids processors support PC5-5600B or PC5-5200B memory, while 4th Gen Sapphire Rapids models support PC5-4800B only. This module therefore belongs in 5th Gen systems.
Speed then depends on population. With one DIMM per channel the module can run at 5600 MT/s on a processor that supports it; with two per channel, HPE lists 4400 MT/s for 5th Gen configurations on the DL380a Gen11. Gen12 servers use DDR5-6400 kits like the P69728-B21 64GB DDR5-6400 instead.
HPE does not support rank mixing, x4 and x8 mixing within a socket, or mixing different RDIMM types on Gen11. Fill each processor’s channels with identical 32GB 2Rx8 modules and keep the quantity even, as HPE recommends.
If you are tracing a memory fault, the iLO Integrated Management Log normally names the processor and slot that reported the error. Shut the server down, remove power, and swap only that DIMM, taking care to handle the module by its edges. Once the server is back up, the memory summary in iLO or the system utilities should report the expected total capacity. A server that has been upgraded from 4th to 5th Gen processors will need all of its DDR5-4800 modules replaced with 5600 MT/s memory, because HPE does not list the older kits for Emerald Rapids.
Pick New for upgrades or fresh deployments. Its condition and warranty are displayed when you select it.
Pick Refurbished when replacing a single failed module on a budget. Its condition and warranty are displayed when you select it.
| Specification | Details |
|---|---|
| Label code | P53626-0AE |
| Other label code | P53626-0A1 |
| Option kit | P64706-B21 |
| Spare numbers | P65254-001, P68074-001 |
| Capacity | 32GB |
| Module | Registered DDR5 DIMM, 288-pin |
| Rank / width | 2Rx8 |
| Data rate | 5600 MT/s, PC5-44800 |
| Latency | CL46 |
| ECC | Yes |
| Voltage | 1.1V |
| Processor support | 5th Gen Intel Xeon Scalable (Gen11) |
Our listing already covered the ML110, ML350, DL320 and DL360 Gen11. Data for the P64706-B21 kit shows these 5th Gen Xeon systems:
UK delivery is available and you will see the options at checkout. Send us your server model, serial number and the DIMM label details if you would like us to check the part before you buy.
Both labels are listed against the same HPE option kit, P64706-B21, as 32GB 2Rx8 DDR5-5600 registered memory. As long as the speed, rank and organisation match, the -0AE module is a like-for-like replacement.
It is meant for Gen11 servers with 5th Gen Intel Xeon Scalable processors. HPE lists 4th Gen Xeon models as supporting PC5-4800B memory only.
Gen12 platforms use DDR5-6400 memory kits, so choose a 6400 MT/s kit for a Gen12 server rather than this Gen11 module.
The condition and warranty for Refurbished stock are shown on the product page when you select that option.
UK delivery is available. The delivery choices for your address are shown at checkout.
