HPE 699765-001 SN1000Q 16GB 2P FC HBA

HPE 699765-001 StoreFabric SN1000Q 16Gb Dual-Port Fibre Channel HBA

The HPE 699765-001 StoreFabric SN1000Q 16Gb Dual-Port Fibre Channel Host Bus Adapter is an enterprise storage connectivity card designed for compatible HPE servers. Featuring two Fibre Channel ports, it enables servers to communicate with supported storage area networks (SANs) for applications such as virtualisation, database hosting and centralised storage.

Part number 699765-001 identifies the replacement adapter, while QW972A is the corresponding HPE product option. This distinction is useful when sourcing replacement hardware for an existing server.

The SN1000Q supports 16Gb, 8Gb and 4Gb Fibre Channel speeds, allowing compatible installations to continue using existing SAN equipment.

HPE 699765-001 Technical Specifications

Important: HPE’s spare-part description references PCI Express 2.0, while the QW972A option QuickSpecs specify PCI Express 3.0 x8. Confirm the physical board revision and server compatibility when replacing an existing adapter.

Key Features and Benefits

• Dual Fibre Channel ports: Provides two independent storage network connections.
• 16Gb connectivity: Supports high-speed access to compatible Fibre Channel storage systems.
• Backward speed compatibility: Supports 8Gb and 4Gb Fibre Channel networks with qualified equipment.
• Storage-path redundancy: Can be configured for separate SAN fabrics when the infrastructure supports multipathing.
• Enterprise workload support: Suitable for compatible database, backup and virtualisation environments.
• Replacement availability: Helps maintain established HPE storage networking configurations without changing adapter families.

HPE ProLiant Server Compatibility

The SN1000Q family is documented for selected HPE ProLiant server generations, including certain G7, Gen8 and Gen9 systems.

HPE server documentation identifies QW972A as a storage option for platforms such as the ProLiant DL580 Gen9 and DL560 Gen9.

Compatibility depends on the precise server model, PCIe riser configuration, firmware and operating system. The presence of a PCIe slot alone does not guarantee support.

Before ordering, verify the server’s supported HBA list and check whether the required mounting bracket and optical transceivers are included.

Dual-Port SAN Connectivity and Redundancy

The two Fibre Channel ports allow administrators to establish separate connections to compatible SAN infrastructure.

For example, one port may connect to a switch in SAN Fabric A while the second connects to SAN Fabric B. When supported by the storage array and operating system multipathing software, this arrangement can provide alternative paths to shared storage.

However, dual-port hardware does not automatically guarantee high availability. Correct SAN zoning, storage presentation, switch configuration and multipathing are also required.

The 699765-001 is a Fibre Channel storage adapter, not an Ethernet network interface card or iSCSI controller.

SN1000Q vs SN1100Q and SN1600Q

When planning a replacement or upgrade, it is important to distinguish the adapter families:

• 699765-001 / QW972A: SN1000Q 16Gb dual-port Fibre Channel HBA.
• QW971A: SN1000Q 16Gb single-port Fibre Channel HBA.
• P9D93A: SN1100Q 16Gb single-port Fibre Channel HBA.
• P9D94A: SN1100Q 16Gb dual-port Fibre Channel HBA.
• P9M76A: SN1600Q 32Gb dual-port Fibre Channel HBA.

Although these adapters perform similar storage networking functions, they are not automatically interchangeable. Verify the server’s qualified adapter list before selecting an alternative.

Installation and Maintenance Considerations

Install the SN1000Q in a supported server expansion slot, following the relevant HPE maintenance instructions.

The original QW972A retail option was documented with two 16Gb SFP+ transceivers and both standard and low-profile brackets. A replacement spare or Refurbished adapter may be supplied with different accessories.

After installation, confirm that both Fibre Channel ports are recognised, apply the appropriate qualified firmware and drivers, and verify the optical links.

For production use, ensure the SAN switches and storage arrays are correctly configured before presenting storage volumes to the server.

New and Refurbished HPE 699765-001

New: New or unused 699765-001 adapters may be suitable for maintaining established HPE SAN environments. Confirm stock availability, packaging, transceiver inclusion and warranty terms before purchasing.

Refurbished: A Refurbished adapter can provide a cost-effective replacement for an existing SN1000Q installation. Buyers should request confirmation of hardware testing, Fibre Channel port operation, connector condition and included mounting accessories.

For either condition, confirm the supplied part number, compatibility, warranty coverage and UK delivery arrangements.

Related HPE Fibre Channel and Storage Products

Explore additional HPE server and SAN hardware from Euroland IT Store:

• HPE P9D93A SN1100Q 16Gb Single-Port FC HBA – A newer-generation single-port Fibre Channel adapter.
• HPE 863010-001 SN1100Q 16Gb FC HBA – A service spare from the SN1100Q adapter family.
• HPE P9M76A SN1600Q 32Gb Dual-Port FC HBA – A 32Gb dual-port adapter for qualified server configurations.
• HPE Q0L11A SN1600E 32Gb Single-Port FC HBA – An alternative 32Gb Fibre Channel adapter family.
• HPE Q1J06A MSA 2050 Disk Enclosure – A storage expansion component for supported MSA arrays.

Related products are provided for browsing and are not necessarily compatible replacements for 699765-001.

Buy HPE 699765-001 Fibre Channel HBA in the UK

Euroland IT Store helps UK businesses source Fibre Channel adapters, server spares and enterprise storage hardware. Contact our team to confirm HPE 699765-001 availability, New or Refurbished condition, included SFP+ transceivers, warranty, pricing and UK delivery.

For compatibility assistance, provide your server model, operating system and existing HBA part number.

Request a Quote for HPE 699765-001

Frequently Asked Questions

1. What is HPE 699765-001?

HPE 699765-001 is a StoreFabric SN1000Q 16Gb dual-port Fibre Channel Host Bus Adapter spare used to connect compatible servers to Fibre Channel SANs.

2. What is the difference between 699765-001 and QW972A?

699765-001 is a spare part reference, while QW972A is the corresponding SN1000Q dual-port product option.

3. Does HPE 699765-001 support 8Gb Fibre Channel?

Yes. The SN1000Q supports 16Gb, 8Gb and 4Gb Fibre Channel speeds with compatible storage networking equipment.

4. Does HPE 699765-001 include two SFP+ transceivers?

The original QW972A retail kit was documented with two 16Gb SFP+ transceivers. Replacement spare and Refurbished stock may have different contents, so confirm before ordering.

5. Is HPE 699765-001 available in New and Refurbished condition?

New and Refurbished options may be available through Euroland IT Store. Contact the team to confirm availability, testing, warranty and UK delivery.
