HPE MO001600JXBFP 1.6TB SAS MU SFF SC MV SSD HDD

MO001600JXBFP is one qualified physical model used within HPE’s 1.6TB SAS 12Gb/s Mixed Use SFF Smart Carrier Multi Vendor SSD family. It can appear on the drive label while purchasing records show P49048-B21, service records show P49746-001 and the assembly is P49327-001. This page therefore focuses on model-level identification.

What the Model Label Establishes

Published parts information identifies MO001600JXBFP as a 1.6TB hot-swap SAS 12G SSD using TLC NAND, dual-port SAS, Mixed Use classification and digitally signed firmware when supplied in the associated HPE Smart Carrier family.

Model Profile

Why One Option Can Contain Different Models

Multi Vendor programmes allow HPE to qualify more than one underlying model against a common HPE specification. This helps keep the option and spare identity stable while qualified media can vary between production batches.

Map the Model Back to HPE References

P49327-001 is the assembly, P49746-001 is the spare and P49048-B21 is the option. Recording all four numbers gives administrators both model-level detail and HPE service context.

Mixed Use Is an Endurance Class

Mixed Use is intended for applications with more write activity than a typical Read Intensive workload. It can suit virtual machines, databases and frequently updated data, but actual workload measurement should still guide drive selection.

Dual-Port SAS

Dual-port capability is an enterprise SAS characteristic. Whether both paths are used depends on the system architecture. The drive still needs a supported backplane and controller configuration.

New and Refurbished Model-Matched Drives

New MO001600JXBFP stock can be useful where an organisation wants the same qualified model. Refurbished units can support established systems, with actual drive health and warranty important because flash endurance is consumed by writes.

Comparing a Newer SAS Generation

The P49751-001 6.4TB SAS 24G SSD and P49341-001 assembly provide a useful comparison, but they use Basic Carrier and a newer interface generation rather than this 12G Smart Carrier design.

Identify from the Model Outwards

Euroland IT Store can help map MO001600JXBFP to its related HPE references and source New or Refurbished enterprise SSD stock where available.

Model Records Can Help Firmware Work

Keeping the underlying model in an asset record can help when administrators review drive firmware or investigate behaviour affecting a particular media population. The HPE option remains the commercial specification, while the model provides another level of installed-hardware detail.

Why the Underlying Model Still Matters

Although the HPE option defines the commercial specification, model-level records can be useful when a server contains several drives and an administrator wants to know whether the media population is uniform. This information can support firmware reviews, incident investigation and detailed asset management. It also helps explain why two drives purchased under the same HPE option may carry different manufacturer-level model identifiers while remaining part of the same qualified Multi Vendor family.

Replacement Planning from a Model Label

If MO001600JXBFP is found on a failed drive, the most useful next step is to map it to the HPE assembly and spare rather than search only for an identical model string. That approach preserves the HPE product-family context and can provide more sourcing flexibility where another qualified model fulfils the same HPE specification. Organisations that specifically require model matching can still retain MO001600JXBFP as an additional procurement criterion.

Use the Model as Evidence, Not the Only Criterion

The model number is strong evidence about the underlying SSD, but a complete HPE replacement also involves carrier and commercial qualification. A buyer who searches only for MO001600JXBFP may find bare drives or differently packaged stock. Mapping the model to P49327-001 and P49746-001 helps keep the server-ready HPE configuration visible during purchasing.

Where 1.6TB Capacity Can Fit

The capacity can suit performance-oriented arrays where multiple SFF drives are combined for RAID protection and throughput. Usable space depends on the array layout, so capacity planning should consider the complete group rather than one drive.

Where several qualified models are already installed, model matching may also help keep a RAID group visually and operationally consistent for the maintenance team. The HPE family specification remains the primary compatibility reference.

MO001600JXBFP FAQs

What is MO001600JXBFP?

A qualified model used in HPE’s 1.6TB SAS 12G Mixed Use Multi Vendor SSD family.

Which option is related?

P49048-B21.

Which assembly is related?

P49327-001.

Which spare is related?

P49746-001.

Does it use SAS?

Yes, SAS 12Gb/s.

Why can another model use the same HPE option?

Multi Vendor programmes can qualify multiple underlying models.
