HPE 875217-003 900GB SAS 15K SFF ST HDD

HPE 875217-003 900GB SAS 15K SFF Drive Assembly

HPE 875217-003 is an assembly number for a 900GB, 15,000 rpm disk with a 12Gb/s SAS interface. The disk is 2.5in, runs digitally signed firmware and uses 512n sectors. HPE records place this assembly inside the 870759-B21 SmartCarrier drive (spare 870795-001), and distributor records also list it under 873033-001, the spare for the 872846-B21 standard carrier (ST) drive.

The number usually turns up on a drive label next to the spare and model codes. People look it up to confirm which disk is fitted, or to match disks across several HPE servers that use 900GB 15K drives.

At Euroland IT Store the 875217-003 is sold in New and Refurbished grades, depending on current stock.

HPE 875217-003 Technical Specifications

What Is The HPE 875217-003?

HPE uses four kinds of number on a typical hard drive. The option kit number ends in -B21 and is used for sales. The spare number usually ends in -001 and is used for service. The assembly number, such as 875217-003, tracks the disk build. The model code, such as EH000900JWHPP or EH000900JWCPN, names the disk mechanism.

Because one assembly can be fitted into more than one carrier, the assembly number on its own does not settle which tray you need. Our listing title describes the standard carrier (ST) version. If your existing drive is a SmartCarrier unit, tell us, so we can make sure you receive the right complete drive.

SmartCarrier Or Standard Carrier?

A quick look at the front of your current drive answers this. SmartCarrier drives have a round button and a ring of status lights, and they are standard on ProLiant Gen8, Gen9 and Gen10 servers. Standard carrier drives have a plainer front. Spare 870795-001 means SmartCarrier. Spare 873033-001 means standard carrier.

Handling Drives Safely

Hard drives are sensitive to static and to knocks. Keep the replacement in its anti-static bag until you are ready to fit it. Hold it by the carrier, not the circuit board, and avoid setting it down hard on a desk. Take the same care with the failed drive if it is going back for return or to secure disposal.

New HPE 875217-003

A new 875217-003 suits critical servers and new arrays. You can see the warranty for new stock on the product page.

Refurbished HPE 875217-003

Refurbished stock lowers the cost of keeping 900GB 15K arrays running. It is popular for replacements and for spare kits. The condition grade and warranty are described on the product page.

Compatibility

• Standard carrier version (873033-001): HPE systems with 2.5in standard carrier bays
• SmartCarrier version (870795-001): HPE ProLiant Gen8, Gen9 and Gen10 servers with SFF SmartCarrier bays, and HPE Synergy 480 and 660 modules

Check every number on the label of your current drive, along with the server model and controller, before ordering.

Associated Part Numbers

The finished drives that use this assembly are 870759-B21 with spare 870795-001, and 872846-B21 with spare 873033-001. If you also look after older 15K LFF servers, our catalogue includes HPE 517354-001 (600GB 3.5in 6G 15K), HPE 653952-001 (600GB 6G SAS 15K 3.5in) and HPE EF0600FARNA (600GB 6G SAS 15K 3.5in).

Smaller 15K LFF drives in our range include HPE 533871-002 (450GB 6G SAS 15K 3.5in), while HPE 516810-003 is a 600GB 6G SAS 15K 3.5in drive. For more, see our hard drive spares.

Steps To Confirm The Part

1. Find 875217-003 on the existing drive label.
2. Note the spare number beside it: 870795-001 or 873033-001.
3. Check the front of the carrier for the SmartCarrier light ring.
4. Confirm the array uses 900GB 15K 512n drives.
5. Contact us with the details if the numbers differ.

When Only The Disk Is Needed

Some repairers already have a good carrier and only need the disk. Others need a complete drive ready to slide in. Tell us which you need when you order. If you are reusing a carrier, transfer the disk carefully, use the original screws and make sure the connector lines up with the carrier opening before fitting.

Buying HPE 875217-003 in the UK

We work with UK businesses, IT teams, resellers and repair centres. The product page lists condition, warranty, stock and delivery details for this assembly. For orders over £100 + VAT there is no charge for UK mainland shipping. Please send our team your server model and the label details from your current drive, or call 0203 209 6002.

Frequently Asked Questions On 875217-003

Is the 875217-003 compatible with SmartCarrier and standard carrier bays?

The disk is used in both, but the complete drive must have the carrier your bay expects, so check the spare number on your existing drive.

Should I buy the 875217-003 New or Refurbished?

Choose New for critical servers and new arrays, and Refurbished when you want a lower-cost replacement or spare.

What warranty does the 875217-003 have?

The warranty varies by condition and is shown on the product page.

Do you deliver the 875217-003 across the UK?

Yes, we deliver throughout the UK, and shipping is free to the UK mainland on orders over £100 + VAT.

Is 875217-003 the same as 870795-001?

No, 875217-003 is the assembly number of the disk, while 870795-001 is the spare number of a complete SmartCarrier drive that uses this disk.
