HPE 836267-001 E208e-p SR G10 Controller

HPE 836267-001 Smart Array E208e-p SR Gen10 Controller

The HPE 836267-001 is a replacement Smart Array E208e-p SR Gen10 RAID controller for connecting compatible HPE ProLiant servers to external SAS storage. It provides eight external SAS lanes through two Mini-SAS HD connectors and supports SAS transfer rates of up to 12Gb/s.

Designed as a standard PCIe plug-in card, this controller supports RAID 0, 1, 5 and 10 without dedicated cache memory. It is a practical option for businesses maintaining existing external storage enclosures or replacing a failed E208e-p controller.

Technical Specifications

External Storage Connectivity for Gen10 Servers

The E208e-p is intended for external storage rather than internal server drive bays. Its two Mini-SAS HD ports provide connections to compatible disk enclosures using the appropriate external SAS cables.

HPE lists several supported external storage platforms, including:

• HPE D3610 Disk Enclosure
• HPE D3710 Disk Enclosure
• HPE D6020 Disk Enclosure
• Selected HPE MSA 1040, 1050, 2040 and 2050 storage configurations

Enclosure support depends on the specific storage configuration, firmware and connection requirements. Confirm compatibility before ordering, especially when connecting an existing MSA system.

RAID and HBA Options

The HPE 836267-001 supports RAID 0, 1, 5 and 10 for compatible external drives. It also offers Mixed Mode, allowing RAID logical drives and physical drives operating in HBA mode to be used simultaneously.

Because the E208e-p is a cacheless controller, it does not provide dedicated flash-backed write cache. Businesses requiring a cached external RAID controller should assess a compatible alternative, such as the Smart Array P408e-p.

RAID redundancy can help maintain storage availability, but it does not replace regular backups.

Server Compatibility and Installation

HPE documents E208e-p support for selected ProLiant Gen10 servers, including DL360 Gen10, DL380 Gen10, DL560 Gen10, DL580 Gen10, ML110 Gen10 and ML350 Gen10 models.

The controller requires a suitable PCIe expansion slot. Unlike the E208i-a modular controller, it does not install into a dedicated Type-a storage controller slot.

Before replacing your controller, check the server’s supported hardware list, PCIe slot availability, controller firmware and external SAS cables. The E208e-p uses external Mini-SAS HD connectors, so cables intended for older Mini-SAS interfaces may not fit.

New and Refurbished HPE 836267-001

New Controller

A New or unused HPE 836267-001 may be suitable for planned maintenance or replacement stock in an existing Gen10 environment. As this is an older controller generation, confirm whether unused legacy stock is available and which accessories are supplied.

Refurbished Controller

A Refurbished E208e-p controller can provide a cost-conscious way to maintain existing external storage systems. Before ordering, ask whether the card has been inspected and tested for controller detection and external SAS connectivity.

For both conditions, confirm the supplied PCIe bracket, warranty terms and UK delivery arrangements.

Related HPE Controllers and Server Hardware

Explore other HPE components for enterprise storage maintenance:

• HPE 836259-001 E208i-a SR Gen10 Controller – An internal modular RAID controller, not a direct replacement for the external E208e-p.
• HPE 804329-001 E208i-a Controller – A related assembly-number listing for the internal E208i-a model.
• HPE 462918-001 Smart Array P411 Controller – An older external SAS controller using a different connector generation.
• HPE 868704-B21 DL380 Gen10 CTO Server – A related server platform supporting selected PCIe storage controllers.
• HPE P24849-B21 DL380 Gen10 Rack Server – A preconfigured Gen10 server for enterprise applications.

These products are provided for comparison and browsing. They are not automatically included with HPE 836267-001 or guaranteed to be interchangeable.

Order HPE 836267-001 in the UK

Euroland IT Store helps UK businesses source HPE RAID controllers, external storage components and replacement server hardware.

Contact our team to check New or Refurbished availability, warranty and UK delivery. For a replacement enquiry, provide your server model, external storage enclosure model and existing controller part number.

Request a Quote for HPE 836267-001

Frequently Asked Questions

1. What is HPE 836267-001?

HPE 836267-001 is the replacement spare number for the Smart Array E208e-p SR Gen10 external SAS RAID controller.

2. Does HPE 836267-001 connect to internal or external drives?

It is designed for external SAS storage and provides two external Mini-SAS HD ports. It is not an internal drive-bay controller.

3. Does the E208e-p controller include cache memory?

No. The Smart Array E208e-p SR Gen10 is a cacheless controller supporting RAID 0, 1, 5 and 10.

4. Which external storage enclosures support the E208e-p?

HPE lists the D3610, D3710 and D6020 disk enclosures, along with selected MSA storage systems. Compatibility must be confirmed for the specific enclosure and firmware configuration.

5. Can I buy HPE 836267-001 in New or Refurbished condition?

New and Refurbished options may be available through Euroland IT Store. Contact the team to confirm stock, included accessories, warranty and UK delivery.
