HPE 768788-002 600GB 10K RPM SAS 12G SC HDD

HPE 768788-002 600GB 10K SAS 12G SFF Enterprise Hard Drive

If the label on your failed drive reads 768788-002, you are looking at an HPE assembly number for a 600GB Enterprise SAS drive. It is a 2.5 inch small form factor disk that spins at 10,000 rpm and connects at 12Gb/s. Parts cross-references place it under HPE option kit 781516-B21 and spare part 781577-001, which are supplied in the SmartDrive Carrier (SC).

The 600GB 10K size is a middle ground. It gives twice the space of a 300GB boot drive while keeping Enterprise-class response times, so it is often used for application data, smaller virtual machine stores, SQL instances with moderate load and Exchange or file server roles in smaller offices.

The 768788-002 can be ordered from Euroland IT Store as New or Refurbished stock, subject to current availability.

HPE 768788-002 Technical Specifications

What Is The HPE 768788-002?

An HPE assembly number tells you which build of a drive you have. For 768788-002, the matching option kit is 781516-B21 and the matching spare is 781577-001. The same drive also appears under other assembly numbers, including 781514-001, 781581-001, 796365-002 and 869714-002, and under model numbers such as EG0600JEHMA and EG000600JWEBH.

Take care with the suffix. The 768788 base number is shared across capacities, with 768788-001 listed as 300GB and 768788-004 as 1.2TB. The -002 version is the 600GB drive, so match all of the digits before you order.

Balancing Capacity And Speed With 600GB 10K Drives

Why not just buy a bigger Midline drive? Because rotational speed has a direct effect on how quickly the drive can reach scattered data. At 10,000 rpm, average rotational latency is about 3 milliseconds, against roughly 4.2 milliseconds at 7,200 rpm. For workloads with lots of small random requests, that gap adds up across thousands of operations per second.

Enterprise drives are also designed for heavier, round-the-clock duty than Midline models. A RAID 10 set of 600GB 10K drives remains a common, cost-aware layout for busy application servers that do not yet justify SSDs.

New HPE 768788-002

New units suit projects that need untouched hardware, such as a fresh RAID 10 build or a strict replacement policy. Condition and warranty terms for New stock appear on the product page.

Refurbished HPE 768788-002

Refurbished units offer a cost-conscious way to replace one or two failed drives without changing the whole array. Please see the product page for the condition and warranty of Refurbished stock.

Compatibility

• HPE ProLiant DL380 Gen9 and DL380 Gen10
• HPE ProLiant DL360 Gen9 and DL360 Gen10
• HPE ProLiant DL380p Gen8 and DL360p Gen8
• HPE ProLiant ML350 Gen9 and ML350 Gen10
• HPE ProLiant BL460c Gen9 and Gen10
• HPE Synergy 480 Gen10

The list is drawn from PartSurfer-based data and is a guide rather than a guarantee. Check your server model, controller, bay type and the label on the drive being replaced.

Related Part Numbers

• HPE 781516-B21: the option kit for this 600GB drive
• HPE EG0600JEHMA: a drive model number reported for it
• HPE 787646-001: a 600GB 2.5 inch 10K drive listing
• HPE 872477-B21: a 600GB SAS 12G 10K 2.5 inch drive listing
• HPE 652583-B21: an older 600GB 6G SAS 10K SFF option
• HPE 653957-001: an older 600GB 6G SAS 10K SFF spare

Confirming The Match

1. Read the whole label and check the number ends in -002.
2. Look for 781516-B21, 781577-001 or EG0600JEHMA nearby.
3. Confirm the drive is 600GB, 10K and SAS 12G.
4. Check whether your replacement needs to come with an SC carrier.
5. Make sure the rest of the array uses the same speed and size.

RAID 10 Rebuilds With 600GB Drives

In RAID 10, each drive has a mirror partner. When one fails, only that pair is exposed, and the rebuild copies data from the surviving partner. That makes rebuilds on 600GB 10K drives fairly quick compared with parity arrays. Even so, replace the failed drive promptly, as losing the partner before the rebuild ends would take the array offline.

Buying HPE 768788-002 in the UK

Euroland supplies HPE drives to UK companies, in-house IT, resellers and repair specialists. Refer to the product page for current condition, warranty, stock and delivery details. Shipping is free to UK mainland addresses for orders above £100 + VAT. To double-check compatibility, share your server model and all the part numbers on the old drive with our team, or call 0203 209 6002.

Frequently Asked Questions

Which servers is the HPE 768788-002 compatible with?

The 600GB drive linked to 768788-002 is listed for HPE ProLiant Gen8, Gen9 and Gen10 servers with SFF bays, such as the DL360, DL380 and ML350, so please confirm your model.

Is 768788-002 the same as 781516-B21?

Cross-reference data lists 768788-002 as an assembly number for the 600GB 12G SAS 10K SFF drive sold as option kit 781516-B21 and spare part 781577-001.

Should I pick a New or Refurbished 768788-002?

Pick New for fresh arrays or unused-part policies, and Refurbished for an economical replacement in an existing server.

What is the warranty on the 768788-002?

Each condition carries the warranty shown on the product page, and our team can confirm the terms before you order.

Do you deliver the 768788-002 throughout the UK?

Yes, we deliver throughout the UK, and orders over £100 + VAT ship free to the UK mainland.
